Our Capabilities
- Dielectric Withstand
- Hi-Potential Testing
- Voltage Drop
- Contact Resistance
- Gate Leakage
- Insulation Integrity
- Dielectric Integrity
Common Electrical Test Specifications
AEC Q100-
Stress Test Qualification for Integrated Circuits
AEC Q101-
Stress Test Qualification for Discrete Semiconductors
AEC Q200-
Stress Test Qualification for Passive Components
ANSI/EIA-364-23B-
Low Level Contact Resistance Test Procedure for Electrical Connectors and Sockets
ANSI/EIA/ECA-364-29C-
Contact Retention Test for Electrical Connectors
ANSI/EIA-364-1000.01-
Environmental Test Methodology for Assessing the Performance of Electrical Connectors and Sockets Used in Business Office Applications
ASTM D149-
Standard Test Method for Dielectric Breakdown Voltage and Dielectric Strength of Solid Electrical Insulating Materials at Commercial Power Frequencies
ASTM D150-
Standard Test Method for AC Loss Characteristics & Permittivity (Dielectric Constant) of Solid Electrical Insulation
ASTM D257-
Standard Test Method for DC Resistance or Conductance of Insulating Materials
ASTM D3755-
Standard Test Method for Dielectric Breakdown Voltage & Dielectric Strength of Solid Electrical Insulating Materials Under Direct-Voltage Stress
AS 1334.9-
Determination of Electrical Resistance of Conveyor Belting
GM9110P-
Procedure for Testing Switches
GME 3191-
Electrical Connectors
GMI 12558-
General Specification for Electrical/Electronic Subsystems & Components Environmental Requirements
IEC 60512-2-1-
Electrical Continuity and Contact Resistance Tests
IEC 60512-3-1-
Insulation Tests
IEC 60512-4-1-
Voltage Stress Tests
IEC 60512-5-1-
Current Carrying Capacity Tests
IPC-TM-650, Sect.2.5.7-
Dielectric Withstanding Voltage,Printed Wiring Material
IPC-TM-650, Sect.2.5.32-
Resistance Test, Plated Through-Holes
IPC-TM-650, Sect.2.6.3.3-
Surface Insulation Resistance,Fluxes
IPC-TM-650, Sect.2.6.3.4-
Moisture and Insulation Resistance-Conformal Coating
ISO 16750-
Road Vehicles-Environmental Conditions and Testing for Electrical and Electronic Equipment-Electrical Loads
MIL-I-22834A-
Insulation, Electrical,Dielectric Barrier, Laminated, Plastic Film and Synthetic Fiber Mat
MIL-STD-202G-
Military Standard Test Method for Electronic & Electrical Component Parts
MIL-STD-750D-
Test Methods for Semi-Conductor Devices
MIL-STD-810F-
Military Standard Environmental Test Methods
MIL-STD-883G-
Microcircuits
MIL-STD-1344A-
Test Methods for Electrical Connectors
SAE J1455-
Joint SAE/TMC Recommended Environmental Practices for Electronic Equipment Design (Heavy-Duty Trucks)
SAE/USCAR-2-
Standard for Automotive Electrical Connection Systems
SAE/USCAR-15-
Specification for Testing Automotive Miniature Bulb Socket/Circuit Plate Assemblies
TSC7000G-
Test Method for Auto Electrical Equipment
TSC7306G-
Bench Test Methods for Electronically Controlled Functional Body Components
